STACKER & LIFT TABLE
TOYO-INTL EHS Electric Stacker
The side-drive design reduces the operating channel and turning radius for better visibility and work in narrow spaces. The extended operation handle is intended for walk-behind operation and ergonomic use. The key switch, electric meter, lift/lower buttons, and turtle-speed switch are integrated into the operation handle. An external charger is specified to improve heat dissipation and avoid vibration damage to a built-in charger while the vehicle is running. Reinforcing ribs between the inner and outer masts help prevent mast or door-frame tilt and improve stability. A Germany-imported waterproof micro-power switch is specified for cold, moist, dusty, and otherwise harsh environments. The operation handle uses an air-pressure spring that releases and automatically resets.
Product Details
- The side-drive design reduces the operating channel and turning radius for better visibility and work in narrow spaces.
- The extended operation handle is intended for walk-behind operation and ergonomic use.
- The key switch, electric meter, lift/lower buttons, and turtle-speed switch are integrated into the operation handle.
- An external charger is specified to improve heat dissipation and avoid vibration damage to a built-in charger while the vehicle is running.
- Reinforcing ribs between the inner and outer masts help prevent mast or door-frame tilt and improve stability.
- A Germany-imported waterproof micro-power switch is specified for cold, moist, dusty, and otherwise harsh environments.
- The operation handle uses an air-pressure spring that releases and automatically resets.
Technical Specifications
| Model | Rated traction weight (kg) | Lifting height (m) | Min. fork height (mm) | Overall length/width (mm) | Fork size (mm) | Width of fork (mm) | Battery voltage/rated capacity (V/Ah) | Type of steering | Wheels type | Type of battery |
|---|---|---|---|---|---|---|---|---|---|---|
| EHS1.2T | 1200 | 1.6/2/2.5/3/3.5 | 90 | 1745/795 | 60/180/1150 | 570/685 | 24/100 | Mechanical | PU | Lead-acid/Lithium |
| EHS1.5T | 1500 | 1.6/2/2.5/3/3.5/4 | 86 | 1740/795 | 60/160/1150 | 570/695 | 24/100 | Mechanical | PU | Lead-acid/Lithium |
