TOYO-INTL G80 LSE Type Swivel Eye Bolt Lifting Point with Integrated Key
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
The key eye point is specified with a 4:1 safety factor. It uses high-quality alloy steel and professional forging technology. The source states that specifications are complete for customized needs. The production process and raw materials are traceable. The unit is designed for easy installation. The bolt has an anti-corrosion design for more conditions. The source specifies DIN EN 1677-1, bolt grade 10.9, and 6g go/no-go inspection. Opening the stopper allows 360° rotation; the image also shows vertical lifting as the optimal-load direction and angled force guidance.
Product Details
- The key eye point is specified with a 4:1 safety factor.
- It uses high-quality alloy steel and professional forging technology.
- The source states that specifications are complete for customized needs.
- The production process and raw materials are traceable.
- The unit is designed for easy installation.
- The bolt has an anti-corrosion design for more conditions.
- The source specifies DIN EN 1677-1, bolt grade 10.9, and 6g go/no-go inspection.
- Opening the stopper allows 360° rotation; the image also shows vertical lifting as the optimal-load direction and angled force guidance.
Technical Specifications
Parameters — metric thread (as printed; removed schematic columns: E, D, F, W, S; A/B/C were already absent)
| Item | WLL/T | Thread | Locking torque/Nm | N.G./kg |
|---|---|---|---|---|
| LSE-M8 | 0.3 | M8-1.25 | 10-40 | 0.12 |
| LSE-M10 | 0.4 | M10-1.5 | 10-40 | 0.13 |
| LSE-M12 | 0.75 | M12-1.75 | 15-40 | 0.2 |
| LSE-M14 | 0.75 | M14-2.0 | 30-100 | 0.2 |
| LSE-M16 | 1.5 | M16-2.0 | 45-130 | 0.4 |
| LSE-M18 | 1.5 | M18-2.5 | 100-170 | 0.4 |
| LSE-M20 | 2.3 | M20-2.5 | 100-170 | 0.6 |
| LSE-M22 | 2.3 | M22-2.5 | 100-170 | 0.6 |
| LSE-M24 | 3.2 | M24-3.0 | 190-280 | 1.0 |
| LSE-M27 | 3.2 | M27-3.0 | 250-500 | 1.0 |
| LSE-M30 | 4.5 | M30-3.5 | 270-600 | 1.9 |
| LSE-M33 | 4.5 | M33-3.5 | 270-600 | 1.9 |
| LSE-M36 | 7.0 | M36-4.0 | 270-600 | 3.6 |
| LSE-M42 | 9.0 | M42-4.5 | 350-800 | 5.6 |
| LSE-M48 | 12.0 | M48-5.0 | 350-800 | 8.5 |
Parameters — UNC thread (as printed; removed schematic columns: E, D, F, W, S; A/B/C were already absent)
| Item | WLL/T | Thread | TPI | Locking torque/Nm | N.G./kg |
|---|---|---|---|---|---|
| LSE-5/16 | 0.3 | 5/16 | 18 | 10-40 | 0.15 |
| LSE-3/8 | 0.4 | 3/8 | 16 | 10-40 | 0.15 |
| LSE-1/2 | 0.75 | 1/2 | 13 | 15-40 | 0.2 |
| LSE-5/8 | 1.5 | 5/8 | 11 | 45-130 | 0.35 |
| LSE-3/4 | 2.3 | 3/4 | 10 | 45-130 | 0.6 |
| LSE-7/8 | 2.3 | 7/8 | 9 | 100-170 | 0.6 |
| LSE-1 | 3.2 | 1 | 8 | 190-280 | 1.0 |
| LSE-1-1/4 | 4.5 | 1-1/4 | 7 | 270-600 | 2.0 |
| LSE-1-1/2 | 7 | 1-1/2 | 6 | 270-600 | 3.8 |
| LSE-1-3/4 | 9 | 1-3/4 | 5 | 350-800 | 5.0 |
| LSE-2 | 12 | 2 | 4.5 | 350-800 | 7.5 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
