TOYO-INTL G80 Nut Type Swivel Hoist Ring with Female Thread
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
The product is presented as a nut-type hoist ring with a female metric thread. The printed metric thread range is M8–M100. The printed working-load range is 0.4–40 t. The ring rotates through 360°. The ring pivots through 230°.
Product Details
- The product is presented as a nut-type hoist ring with a female metric thread.
- The printed metric thread range is M8–M100.
- The printed working-load range is 0.4–40 t.
- The ring rotates through 360°.
- The ring pivots through 230°.
Technical Specifications
| Item | WLL/T | Thread | N.G./kg |
|---|---|---|---|
| NYH-M8 | 0.4 | M8×1.25 | 0.7 |
| NYH-M10 | 0.6 | M10×1.5 | 0.7 |
| NYH-M12 | 0.7 | M12×1.75 | 0.7 |
| NYH-M14 | 1.25 | M14×2.0 | 0.7 |
| NYH-M16 | 1.5 | M16×2.0 | 0.7 |
| NYH-M18 | 2.0 | M18×2.5 | 3.2 |
| NYH-M20 | 2.5 | M20×2.5 | 3.2 |
| NYH-M22 | 2.5 | M22×2.5 | 3.2 |
| NYH-M24 | 4 | M24×3.0 | 3.2 |
| NYH-M30 | 6 | M30×3.5 | 5.3 |
| NYH-M33 | 7.5 | M33×3.5 | 5.3 |
| NYH-M36 | 10 | M36×4.0 | 5.2 |
| NYH-M39 | 10 | M39×4.0 | 5.1 |
| NYH-M42 | 13 | M42×4.5 | 8.3 |
| NYH-M45 | 13 | M45×4.5 | 8.1 |
| NYH-M48 | 14 | M48×5.0 | 8 |
| NYH-M52 | 20 | M52×5.0 | 13.8 |
| NYH-M56 | 20 | M56×5.5 | 13.5 |
| NYH-M60 | 20 | M60×5.5 | 13.2 |
| NYH-M64 | 20 | M64×6.0 | 12.9 |
| NYH-M72 | 31.5 | M72×6.0 | 48 |
| NYH-M80 | 35 | M80×6.0 | 48 |
| NYH-M90 | 40 | M90×6.0 | 52 |
| NYH-M100 | 40 | M100×6.0 | 50 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
