HEAVY DUTY EQUIPMENT
TOYO-INTL Gantry Crane
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
Four portable parts are assembled with only four bolts. Leg assembly is stated to take 2–3 minutes. 360-degree swivel-locking casters are standard for positioning. All-terrain and uneven-ground caster options are available. Height and span are adjusted manually. The source shows an ultra-safe captive trolley.
Product Details
- Four portable parts are assembled with only four bolts.
- Leg assembly is stated to take 2–3 minutes.
- 360-degree swivel-locking casters are standard for positioning.
- All-terrain and uneven-ground caster options are available.
- Height and span are adjusted manually.
- The source shows an ultra-safe captive trolley.
Technical Specifications
| Model | Product size (mm) | Lifting stroke (mm) | Span (mm) | Net weight (kg) | Gross weight (kg) | Double tee iron |
|---|---|---|---|---|---|---|
| SGCA-1T | 2600x1204x2433 | 2300-3500 | 2360 | 140 | 164 | 14 |
| SGCA-2T | 2600x1204x2549 | 2400-3600 | 2340 | 172 | 197.5 | 18 |
| SGCA-1TPro | 2400x1204x2510 | 2400-3700 | 1900 | 200 | 238 | 16 |
| SGCA-1TPlus | 2800x1500x3000 | 3000-4200 | 3200 | 155 | 187 | 14 |
| SGCA-2TPlus | 2800x1500x3000 | 3000-4200 | 3200 | 196 | 227 | 18 |
| SGCA-3T | 3500x2000x3000 | 3000-4000 | 3500 | 396 | 426 | 25 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
