LEVER HOIST
TOYO-INTL HSH Lever Hoist
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
The product is presented as a mini lever block. Capacity options printed in the table are 250, 500, 750 and 1500 kg. Standard lift is 1.5 m for all four listed capacities. Printed test loads are 375, 750, 1125 and 2250 kg. The hand-pull-to-lift entries are 260, 260, 200 and 240 N. The load-chain entries are Φ4×12, Φ4×12, Φ5×15 and Φ7×21 mm. Printed net/gross weights range from 2.15/2.2 to 7.6/8 kg.
Product Details
- The product is presented as a mini lever block.
- Capacity options printed in the table are 250, 500, 750 and 1500 kg.
- Standard lift is 1.5 m for all four listed capacities.
- Printed test loads are 375, 750, 1125 and 2250 kg.
- The hand-pull-to-lift entries are 260, 260, 200 and 240 N.
- The load-chain entries are Φ4×12, Φ4×12, Φ5×15 and Φ7×21 mm.
- Printed net/gross weights range from 2.15/2.2 to 7.6/8 kg.
Technical Specifications
| Parameter | 250 kg | 500 kg | 750 kg | 1500 kg |
|---|---|---|---|---|
| Capacity (kg) | 250 | 500 | 750 | 1500 |
| Standard lift (m) | 1.5 | 1.5 | 1.5 | 1.5 |
| Test load (kg) | 375 | 750 | 1125 | 2250 |
| Hand-pull to lift (N) | 260 | 260 | 200 | 240 |
| Extra weight for one meter chain added (kg/m) | 0.346 | 0.346 | 0.541 | 1.1 |
| Load chain (dia. × pitch) (mm) | Φ4×12 | Φ4×12 | Φ5×15 | Φ7×21 |
| N.W./G.W. (kg) | 2.15/2.2 | 3.1/3.2 | 4.75/4.85 | 7.6/8 |
