TOYO-INTL KBK Flexible Track Crane System Modular Overhead Track
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
The track uses Q355b steel with a stated yield strength over 1.5 times ordinary Q235b steel. Q355d for low-temperature environments and 304 stainless steel are listed as options. An integrated one-piece structure requires no welding. One-time roll forming is described as high precision, with rail lengths up to 15 m. Rail straightness is stated to reach 0.5 mm/m or better. An 8 mm steel-wire-rope secondary protection is tested to a 3.8-ton safety limit. The source says the secondary protection requires no assembly and can save 90% of installation time. The trolley uses physical anti-fall protection and high-quality molded nylon from Asahi Kasei or BASF.
Product Details
- The track uses Q355b steel with a stated yield strength over 1.5 times ordinary Q235b steel.
- Q355d for low-temperature environments and 304 stainless steel are listed as options.
- An integrated one-piece structure requires no welding.
- One-time roll forming is described as high precision, with rail lengths up to 15 m.
- Rail straightness is stated to reach 0.5 mm/m or better.
- An 8 mm steel-wire-rope secondary protection is tested to a 3.8-ton safety limit.
- The source says the secondary protection requires no assembly and can save 90% of installation time.
- The trolley uses physical anti-fall protection and high-quality molded nylon from Asahi Kasei or BASF.
Technical Specifications
| Capacity (kg) | Rail group | Parameter | Value |
|---|---|---|---|
| 125 | I | Span IKT (source unit not printed) | 6.2 |
| 125 | I | Girder length IHT (source unit not printed) | 9.0 |
| 250 | I | Span IKT (source unit not printed) | 5.0 |
| 250 | I | Girder length IHT (source unit not printed) | 6.0 |
| 500 | I | Span IKT (source unit not printed) | 3.1 |
| 500 | I | Girder length IHT (source unit not printed) | 4.0 |
| 500 | II | Span IKT (source unit not printed) | 8.5 |
| 500 | II | Girder length IHT (source unit not printed) | 9.0 |
| 1000 | II | Span IKT (source unit not printed) | 6.0 |
| 1000 | II | Girder length IHT (source unit not printed) | 6.5 |
| 2000 | II | Span IKT (source unit not printed) | 3.0 |
| 2000 | II | Girder length IHT (source unit not printed) | 3.5 |
Features & Benefits
Additional product images are not available yet.
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
