ELECTRIC HOIST
TOYO-INTL KDB Electric Chain Hoist
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
Electric chain hoist with trolley, as stated by the image title and shown in the trolley drawings. Main table lists 1T through 10T configurations. Lifting height is 4 m throughout the main table. Load-chain diameters shown are 7.1, 10.0 and 11.2 mm. Three-phase 220–480 V and 50/60 Hz are shown across the main table. Trolley travelling speed is shown as 11/1 21/1 m/min.
Product Details
- Electric chain hoist with trolley, as stated by the image title and shown in the trolley drawings.
- Main table lists 1T through 10T configurations.
- Lifting height is 4 m throughout the main table.
- Load-chain diameters shown are 7.1, 10.0 and 11.2 mm.
- Three-phase 220–480 V and 50/60 Hz are shown across the main table.
- Trolley travelling speed is shown as 11/1 21/1 m/min.
Technical Specifications
The source has a merged model label ELECTRIC HOIST KDB, so KDB is retained as the model family and the row capacity labels are transcribed as the configuration key.
| Model family | Load-capacity label | Lifting height (m) | Load-chain diameter (mm) | Chain fall number | Lifting speed (m/min) | Travelling speed (m/min) | Lifting motor power (kW) | Phase | Voltage (V) | Frequency (Hz/s) | Running motor power (kW) | Running motor voltage (V) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KDB | 1T | 4 | 7.1 | 1 | 6.8 | 11/1 21/1 | 1.5 | 3Phase | 220v–480v | 50/60Hz | 0.4 | 220v–480v |
| KDB | 2T | 4 | 10.0 | 1 | 6.6 | 11/1 21/1 | 3 | 3Phase | 220v–480v | 50/60Hz | 0.4 | 220v–480v |
| KDB | 2T | 4 | 7.1 | 2 | 3.4 | 11/1 21/1 | 1.5 | 3Phase | 220v–480v | 50/60Hz | 0.4 | 220v–480v |
| KDB | 3T | 4 | 11.2 | 1 | 5.6 | 11/1 21/1 | 3 | 3Phase | 220v–480v | 50/60Hz | 0.75 | 220v–480v |
| KDB | 3T | 4 | 10.0 | 2 | 3.3 | 11/1 21/1 | 3 | 3Phase | 220v–480v | 50/60Hz | 0.75 | 220v–480v |
| KDB | 5T | 4 | 11.2 | 2 | 2.8 | 11/1 21/1 | 3 | 3Phase | 220v–480v | 50/60Hz | 0.75 | 220v–480v |
| KDB | 7.5T | 4 | 11.2 | 3 | 1.8 | 11/1 21/1 | 3 | 3Phase | 220v–480v | 50/60Hz | 0.75 | 220v–480v |
| KDB | 10T | 4 | 11.2 | 4 | 2.8 | 11/1 21/1 | 3×2 | 3Phase | 220v–480v | 50/60Hz | 0.75 | 220v–480v |
The dimension table also includes a 0.5T row that does not appear in the main table. Its H, A, B, D, E, I, J, K, L, M and N columns are letter-only dimensions and were removed. Net and gross weights are retained.
| Model family | Load-capacity label | Net weight (kg) | Gross weight (kg) |
|---|---|---|---|
| KDB | 0.5T | 19 | 22 |
| KDB | 1T | 36 | 44 |
| KDB | 2T | 47 | 52 |
| KDB | 3T | 57 | 63 |
| KDB | 5T | 76 | 83 |
| KDB | 10T | 124 | 135 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
