LEVER HOIST
TOYO-INTL LBG Lever Hoist
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
The source presents a lever-block range from 0.8 t to 9 t W.L.L. The printed lift is 1.5 m for every listed capacity. Proof-load entries run from 1.2 t to 13.5 t. The load-chain fall count is 1 for 0.8–3.2 t, 2 for 6.3 t and 3 for 9 t. Printed load-chain sizes are 5.6×15.7, 7.1×19.9 and 10×28. The printed lever-force values are retained in their original kg(n)(lbs) form. Net weight is listed from 6.3 kg to 40 kg, with additional-weight entries from 0.7 kg to 6.9 kg per lift.
Product Details
- The source presents a lever-block range from 0.8 t to 9 t W.L.L.
- The printed lift is 1.5 m for every listed capacity.
- Proof-load entries run from 1.2 t to 13.5 t.
- The load-chain fall count is 1 for 0.8–3.2 t, 2 for 6.3 t and 3 for 9 t.
- Printed load-chain sizes are 5.6×15.7, 7.1×19.9 and 10×28.
- The printed lever-force values are retained in their original kg(n)(lbs) form.
- Net weight is listed from 6.3 kg to 40 kg, with additional-weight entries from 0.7 kg to 6.9 kg per lift.
Technical Specifications
| Model | W.L.L. (t) | Lift (m) | Proof load (t) | Lever force kg(n) (lbs) | Load-chain falls | Load-chain size | N.W. (kg) | Additional weight per lift (kg) |
|---|---|---|---|---|---|---|---|---|
| LBG(LBP) 0.8 | 0.8 | 1.5 | 1.2 | 22(215)(48) | 1 | 5.6×15.7 | 6.3 | 0.7 |
| LBG(LBP) 1 | 1 | 1.5 | 1.5 | 30(294)(66) | 1 | 5.6×15.7 | 6.3 | 0.7 |
| LBG(LBP) 1.6 | 1.6 | 1.5 | 2.4 | 31(304)(68) | 1 | 7.1×19.9 | 8.5 | 1.1 |
| LBG(LBP) 3.2 | 3.2 | 1.5 | 4.8 | 38(372)(84) | 1 | 10×28 | 14.2 | 2.3 |
| LBG(LBP) 6.3 | 6.3 | 1.5 | 9.5 | 39(382)(86) | 2 | 10×28 | 26 | 4.6 |
| LBG(LBP) 9 | 9 | 1.5 | 13.5 | 40(392)(88) | 3 | 10×28 | 40 | 6.9 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
