ELECTRIC HOIST
Toyo-Intl New Product New Type TD Electric Hoist
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
Ultra-quiet operation is stated as less than 50 dB. High-strength alloy die-cast body with corrosion resistance and good sealing. High-performance motor described as lightweight, small and powerful. Wide-voltage 360–410 V / 3P / 50 Hz supply is stated. Work class M5, protection class IP55 and insulation class F are stated. Stepless speed change and a 360-degree rotatable forged lifting hook are shown. Grade-7 gear precision and a G80 nickel-plated chain are stated. Upper/lower double limit switches, electromagnetic brake and wireless remote are shown.
Product Details
- Ultra-quiet operation is stated as less than 50 dB.
- High-strength alloy die-cast body with corrosion resistance and good sealing.
- High-performance motor described as lightweight, small and powerful.
- Wide-voltage 360–410 V / 3P / 50 Hz supply is stated.
- Work class M5, protection class IP55 and insulation class F are stated.
- Stepless speed change and a 360-degree rotatable forged lifting hook are shown.
- Grade-7 gear precision and a G80 nickel-plated chain are stated.
- Upper/lower double limit switches, electromagnetic brake and wireless remote are shown.
Technical Specifications
| Source model text | Capacity (the image labels the unit as Ton) | Lifting height (m) | Lifting speed (m/min) | Running speed (m/min) | Hoist power (kW) | Operating power (kW) | Rotation speed (r/min) | Phases | Voltage (V) | Control voltage (V) | Chain diameter (mm) | Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TD0.5-01 | 500 | 4 | 8 | 21 | 0.8 | 0.4 | 1440 | 3/2 | 110-480 | 24-48 | 6.3 | M5 |
| TD 01-01 | 1000 | 4 | 8 | 21 | 1.1 | 0.4 | 1440 | 3/2 | 110-480 | 24-48 | 7.1 | M5 |
| TD01-02 | 1000 | 4 | 8 | 21 | 1.1 | 0.4 | 1440 | 3/2 | 110-480 | 24-48 | 6.3 | M5 |
| TD02 – 01 | 2000 | 4 | 8 | 21 | 2.2 | 0.4 | 1440 | 3/2 | 110-480 | 24-48 | 10.0 | M5 |
| TD02 – 02 | 2000 | 4 | 4 | 21 | 1.1 | 0.4 | 1440 | 3/2 | 110-480 | 24-48 | 7.1 | M5 |
| TD03 – 01 | 3000 | 4 | 7.6 | 21 | 3.0 | 0.8 | 1440 | 3/2 | 110-480 | 24-48 | 11.2 | M5 |
| TD03 – 02 | 3000 | 4 | 4 | 21 | 3.0 | 0.8 | 1440 | 3/2 | 110-480 | 24-48 | 10.0 | M5 |
| TD05 – 02 | 5000 | 4 | 4 | 21 | 3.0 | 0.8 | 1440 | 3/2 | 110-480 | 24-48 | 11.2 | M5 |
| TD7.5 – 03 | 7500 | 4 | 2.7 | 21 | 3.0 | 0.8 | 1440 | 3/2 | 110-480 | 24-48 | 11.2 | M5 |
| TD10 – 04 | 10000 | 4 | 4 | 21 | 3.0×2 | 0.8 | 1440 | 3/2 | 110-480 | 24-48 | 11.2 | M5 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
