LEVER HOIST
Toyo-Intl New Product Weight VLD Display Lever Hoist
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
The New Product Weight VLD Display Lever Hoist provides portable manual lifting and pulling for maintenance, installation and rigging work. Lever operation supports controlled load movement without an external power supply. Forged hooks with safety latches help maintain a secure connection. A mechanical brake supports steady load holding during positioning. Compact construction is practical for confined work areas and frequent relocation. Select the rated capacity and chain length appropriate for each application.
Product Details
- The New Product Weight VLD Display Lever Hoist provides portable manual lifting and pulling for maintenance, installation and rigging work.
- Lever operation supports controlled load movement without an external power supply.
- Forged hooks with safety latches help maintain a secure connection.
- A mechanical brake supports steady load holding during positioning.
- Compact construction is practical for confined work areas and frequent relocation.
- Select the rated capacity and chain length appropriate for each application.
Technical Specifications
| Model | Load Capacity(t) | Standard Lift(m) | Running Test(t) | Effort required to lift max load(N) | Chain Fall Number | Diameter(mm) | Net Weight(kg) | Packing (L*W*H)(cm) | Extra weight meter of extra lift(kg) |
|---|---|---|---|---|---|---|---|---|---|
| VL0.5 | 0.5 | 1.5 | 0.75 | 330 | 1 | 5 | 3.5 | 33.5×12.5×9 | 0.55 |
| VL0.75 | 0.75 | 1.5 | 1.125 | 230 | 1 | 6.3 | 6.6 | 34x12x17 | 0.88 |
| VL1 | 1 | 1.5 | 1.5 | 250 | 1 | 6.3 | 6.6 | 34x12x17 | 0.88 |
| VL1.5 | 1.5 | 1.5 | 2.25 | 295 | 1 | 7.1 | 11 | 45x16x18 | 1.12 |
| VL2 | 2 | 1.5 | 3 | 315 | 1 | 7.1 | 11 | 45x16x18 | 1.12 |
| VL3 | 3 | 1.5 | 4.5 | 414 | 1 | 9 | 17 | 47x20x21 | 1.78 |
| VL6 | 6 | 1.5 | 9 | 430 | 2 | 9 | 27.5 | 47x20x21 | 3.74 |
| VL9 | 9 | 1.5 | 13.5 | 430 | 3 | 9 | 47 | 62×48.5×26 | 5.61 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
