RIGGING HARDWARE
TOYO-INTL RW Wedge Socket
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
The source heading is “WEDGE SOCKET.” The image shows an orange wedge socket and accompanying pin/detail drawings. Size entries run from 6 to 40 mm. The table provides `WEIGHT(KN)` and `B.L.L(KN)` values. Pin entries range from `2×20` to `5×60`. A unit weight in kilograms is listed for every row.
Product Details
- The source heading is “WEDGE SOCKET.”
- The image shows an orange wedge socket and accompanying pin/detail drawings.
- Size entries run from 6 to 40 mm.
- The table provides `WEIGHT(KN)` and `B.L.L(KN)` values.
- Pin entries range from `2×20` to `5×60`.
- A unit weight in kilograms is listed for every row.
Technical Specifications
| Size (mm) | Weight (kN) | B.L.L (kN) | Pin | Weight (kg) |
|---|---|---|---|---|
| 6 | 10 | 43 | 2×20 | 0.56 |
| 8 | 10 | 51 | 2×20 | 0.77 |
| 10 | 15 | 71 | 2×25 | 1.01 |
| 12 | 20 | 100 | 2×25 | 1.77 |
| 14 | 25 | 118.5 | 2×25 | 3.02 |
| 16 | 30 | 161.3 | 3×30 | 4.6 |
| 18 | 35 | 184 | 3×30 | 5.35 |
| 20 | 50 | 249.6 | 3×30 | 7.9 |
| 22 | 55 | 285.3 | 4×50 | 10.8 |
| 24 | 65 | 327 | 4×50 | 18.9 |
| 26 | 75 | 373.6 | 4×50 | 17.2 |
| 28 | 95 | 487.6 | 4×50 | 19.5 |
| 32 | 120 | 600 | 5×60 | 32.9 |
| 36 | 155 | 780 | 5×60 | 43 |
| 40 | 200 | 984 | 5×60 | 55 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
