ELECTRIC HOIST
TOYO-INTL SH Electric Hoist
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
The cylindrical-rotor motor is described as high-performance, high-torque, heat-resistant, pressure-resistant, and suitable for frequent starting. The image marks work class level 5 and IP54 protection. Alloy-steel gears and a high-carbon-steel shaft receive heat treatment. The high-strength nodular-cast-iron gearbox cover is machined for accuracy and reduced vibration. An electromagnetic brake automatically adjusts as the brake disc wears. An auxiliary brake engages when the load drops too fast, forming a double-brake mechanism.
Product Details
- The cylindrical-rotor motor is described as high-performance, high-torque, heat-resistant, pressure-resistant, and suitable for frequent starting.
- The image marks work class level 5 and IP54 protection.
- Alloy-steel gears and a high-carbon-steel shaft receive heat treatment.
- The high-strength nodular-cast-iron gearbox cover is machined for accuracy and reduced vibration.
- An electromagnetic brake automatically adjusts as the brake disc wears.
- An auxiliary brake engages when the load drops too fast, forming a double-brake mechanism.
Technical Specifications
| Model | Capacity (t) | Lifting height options (m) | Lifting motor (kW) | Lift speed (m/min) | Trolley speed (m/min) | Ropes | Rope dia. (mm) | Wire dia. (mm) | Structure form | I-beam type | Minimum curve radius (m) | Hoisting motor type | Hoisting power (kW) | Hoisting rotation (r/min) | Hoisting voltage/frequency | Hoisting current (A) | Trolley motor type | Trolley power (kW) | Trolley rotation (r/min) | Trolley voltage/frequency | Trolley current (A) | Work class | Packaging size variants (cm) | Gross weight variants (kg) | Net weight variants (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SH10 | 1 | 6/12 | 3 | 11 | 21 | 2 ropes | 8 | 0.34 | 6×19-B | 20a–45a | 1.5 | 1M6 | 3 | 1380 | 380V/3F/50Hz | 6.44 | 1T5 | 0.4 | 1380 | 380V/3F/50Hz | 1.5 | M4/30% ED | 99×60×52; 118×60×52 | 208; 236 | 196; 213 |
| SH20 | 2 | 6/12 | 3 | 6.2 | 21 | 2 ropes | 12 | 0.5 | 6×37-B | 20a–45a | 1.8 | 2M7 | 3 | 1380 | 380V/3F/50Hz | 6.44 | 2T5 | 0.4kw5 (source) | 1380 | 380V/3F/50Hz | 1.5 | M4/30% ED | 106×71×64; 126×71×64 | 340; 376 | 305; 336 |
| SH30 | 3 | 6/12 | 5.5 | 7.5 | 21 | 2 ropes | 14 | 0.6 | 6×37-B | 30a–63a | 2.0 | 3M6 | 6 | 1380 | 380V/3F/50Hz | 12.8 | 3T5 | 0.4 | 1380 | 380V/3F/50Hz | 1.5 | M4/30% ED | 118×73×68; 140×73×68 | 454; 495 | 417; 450 |
| SH50 | 5 | 9/12 | 7.5 | 6.7 | 21 | 4 ropes | 12 | 0.6 | 6×37-B | 45a–63a | 3.0 | 5M5 | 7.5 | 1380 | 380V/3F/50Hz | 15.6 | 5T5 | 0.75 | 1380 | 380V/3F/50Hz | 2.2 | M4/30% ED | 164×83×75; 185×83×75 | 739; 785 | 670; 713 |
| SH100 | 10 | 12 | 11 | 5 | 14 | 4 ropes | 16 | 0.7 | 6×37+1-B | 45a–63a | Straight line | 10M | 11 | 1380 | 380V/3F/50Hz | 22 | 5FT5 | 0.75×2 | 1380 | 380V/3F/50Hz | 2.2 | M4/30% ED | 223×94×80 | 2840 | 2640 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
