TOYO-INTL TB Electric Wire Rope Winch
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
The TB Electric Wire Rope Winch supports controlled pulling, positioning or lifting where a compact winch is required. The drive and line arrangement are suited to the product's manual or powered operation. A holding or braking function helps maintain control while the load is positioned. The frame and mounting points support practical installation in the intended work area. Wire rope, webbing or hook fittings should be used only within the rated capacity. Inspect the line, connections and anchor point before each operation.
Product Details
- The TB Electric Wire Rope Winch supports controlled pulling, positioning or lifting where a compact winch is required.
- The drive and line arrangement are suited to the product’s manual or powered operation.
- A holding or braking function helps maintain control while the load is positioned.
- The frame and mounting points support practical installation in the intended work area.
- Wire rope, webbing or hook fittings should be used only within the rated capacity.
- Inspect the line, connections and anchor point before each operation.
Technical Specifications
| Model | Lifting Capacity (kg) | Permanent magnet inverter motor (Kw) | Lifting speed (m/min) | Brake | Lifting height (m) | wire rope (mm×m) | Power supply (m) | Control line (m) | Hook type | N.W (kg) | G.W (kg) | Package size (cm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TB200DS | 200 | 1.5 | 8 / 18 | electric+manual | 28 | 5*30 | 4.5 | 6 | N1 | 18 | 22 | 54*25*30 |
| TB200DS L | 200 | 1.5 | 8 / 18 | electric+manual | 68 | 5*70 | 4.5 | 6 | N1 | 22 | 26 | 60*25*30 |
| TB200DS LL | 200 | 1.5 | 8 / 18 | electric+manual | 118 | 5*120 | 4.5 | 6 | N1 | 25 | 29 | 66*25*30 |
| TB300DS | 300 | 1.5 | 6 / 15 | electric+manual | 28 | 6*30 | 4.5 | 6 | N1 | 18 | 22 | 54*25*30 |
| TB300DS L | 300 | 1.5 | 6 / 15 | electric+manual | 58 | 6*60 | 4.5 | 6 | N1 | 22 | 26 | 60*25*30 |
| TB300DS LL | 300 | 1.5 | 6 / 15 | electric+manual | 88 | 6*90 | 4.5 | 6 | N1 | 25 | 29 | 66*25*30 |
| TB500DS | 500 | 1.5 | 7 / 17 | electric+manual | 28 | 7*30 | 4.5 | 6 | N1 | 18 | 22 | 54*25*30 |
| TB500DS L | 500 | 1.5 | 7 / 17 | electric+manual | 43 | 7*45 | 4.5 | 6 | N1 | 22 | 26 | 60*25*30 |
| TB500DS LL | 500 | 1.5 | 7 / 17 | electric+manual | 58 | 7*60 | 4.5 | 6 | N1 | 25 | 29 | 66*25*30 |
| TB200DSK | 200 | 2.5 | 13 / 35 | electric+manual | 28 | 5*30 | 4.5 | 6 | N1 | 18 | 22 | 54*25*30 |
| TB200DSK L | 200 | 2.5 | 13 / 35 | electric+manual | 68 | 5*70 | 4.5 | 6 | N1 | 22 | 26 | 60*25*30 |
| TB200DSK LL | 200 | 2.5 | 13 / 35 | electric+manual | 118 | 5*120 | 4.5 | 6 | N1 | 25 | 29 | 66*25*30 |
| TB300DSK | 300 | 2.5 | 10 / 26 | electric+manual | 28 | 6*30 | 4.5 | 6 | N1 | 18 | 22 | 54*25*30 |
| TB300DSK L | 300 | 2.5 | 10 / 26 | electric+manual | 58 | 6*60 | 4.5 | 6 | N1 | 22 | 26 | 60*25*30 |
| TB300DSK LL | 300 | 2.5 | 10 / 26 | electric+manual | 88 | 6*90 | 4.5 | 6 | N1 | 25 | 29 | 66*25*30 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
