HAND CHAIN BLOCK
TOYO-INTL VS Chain Block
Price available on request
Why Choose Apex Lifting
Free Tech Support
3-Year Warranty
CE Certified
Support Global Shipping
Product Description:
A roller bearing is shown on the load sprocket. The product uses a flanged enclosure. A pawl is shown as a brake component. An overload device is shown. The listed capacity range is 0.5–50 t. The specification lists 1–22 load-chain strands across the range. Listed load-chain sizes are 6*18, 8*24, and 10*30 mm. Listed net weights range from 8.7 to 1092 kg.
Product Details
- A roller bearing is shown on the load sprocket.
- The product uses a flanged enclosure.
- A pawl is shown as a brake component.
- An overload device is shown.
- The listed capacity range is 0.5–50 t.
- The specification lists 1–22 load-chain strands across the range.
- Listed load-chain sizes are 6*18, 8*24, and 10*30 mm.
- Listed net weights range from 8.7 to 1092 kg.
Technical Specifications
| Parameter | VS-0.5 | VS-1 | VS-1.5 | VS-2 | VS-3 | VS-5 | VS-10 | VS-20 | VS-30 | VS-50 |
|---|---|---|---|---|---|---|---|---|---|---|
| Capacity load (T) | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 20 | 30 | 50 |
| Standard lift (T; source heading) | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Running test load (KN) | 6.13 | 12.25 | 55.8 | 83 | 111.2 | 163.4 | 326.8 | 326.8*2 | 490.2*2 | 898.7*2 |
| Effort required to lift max load (N) | — | — | — | — | — | — | — | — | — | — |
| Strands of load chain | 1 | 1 | 1 | 2 | 2 | 2 | 4 | 8 | 12 | 22 |
| Load-chain diameter (mm) | 6*18 | 6*18 | 8*24 | 8*24 | 8*24 | 10*30 | 10*30 | 10*30 | 10*30 | 10*30 |
| Net weight (kg) | 8.7 | 10.8 | 15.2 | 14.6 | 24.3 | 38.7 | 78 | 163.6 | 220 | 1092 |
| Moving distance of load wheel with one metre lifting | 35 | 35.5 | 45 | 42.5 | 50 | 64 | 85 | 110 | 110 | 170 |
| Extra weight per metre of extra lift (kg) | 1.6 | 1.6 | 2.2 | 2.4 | 3.6 | 5.2 | 9.5 | 19 | 27.7 | 49.4 |
| Packing measurement (L*W*H) (cm) | 22x15x19.5 | 23x18x19.5 | 28x21x24 | 28x21x24 | 32x21x26 | 40x21x21 | 64x21x21 | 64x38x64 | 72x50x68 | 110x100x130 |
Features & Benefits
FAQ
How do you ensure the quality of the products?
Every product undergoes rigorous testing including load testing, material inspection, and CE certification checks before shipment.
How long is your delivery time?
Generally 5–10 days if the goods are in stock, or 15–20 days if not in stock, depending on quantity. We support global shipping via sea, air, and express courier.
Do you provide samples?
Yes, we can arrange samples for evaluation. Contact us with the products you are interested in and any specific requirements.
